Murr Elektronik MSUD Double Valve Connector M12 Cable 24V AC/DC 4A LED Form A

Murr Elektronik MSUD Double Valve Connector M12 Cable 24V AC/DC 4A LED Form A NEW

- Shipping includes tracking info worldwide. Klaus KLJ Trading

• Brand & Model

  • Manufacturer: Murr Elektronik, Czech Republic

  • Type: M12 to dual MSUD valve connector cable assembly

  • Model: MSUD 2 + MSUD 1 double valve configuration

  • Connection: M12 male A-coded to 2x MSUD Form A valve plugs

  • Condition: New, never used, fully functional

  • Made in Czech Republic

• Technical Specifications

  • Voltage rating: 24V AC/DC universal

  • AC voltage tolerance: Plus or minus 20 percent

  • DC voltage tolerance: Plus or minus 25 percent

  • Current rating: 4A maximum per valve connector

  • M12 connector: Male, A-coded, straight or right-angle orientation

  • Valve connector type: 2x MSUD Form A, 18mm pin spacing

  • Protection rating: IP67 on M12 side, IP65 on valve side

• Cable Construction

  • Cable type: Multi-conductor PUR or PVC jacket, gray color

  • Conductor cross-section: 0.75 mm² typical

  • Cable length: Appears to be approximately 300-500mm

  • Configuration: Single cable from M12 to dual valve connectors

  • Strain relief: Integrated on both M12 and valve connector ends

• LED Indicator Features

  • LED type: Green bidirectional light-emitting diodes

  • LED function: Visual indication of voltage presence on each valve coil

  • LED housing: Bright green translucent frames for 360-degree visibility

  • Individual indication: MSUD 1 and MSUD 2 independently monitored

  • Electrical protection: Integrated Z-diodes for voltage spike suppression

• M12 Connector Features

  • Connection type: M12 male, A-coded, 4 or 5-pin

  • Connector body: Metal threaded coupling with nickel plating

  • Locking mechanism: Screw-thread coupling for vibration resistance

  • Contact material: Gold-plated pins for reliable conductivity

  • Cable orientation: Straight rear entry with strain relief

  • IP rating: IP67 when properly mated

• MSUD Valve Connector Features

  • Valve standard: Form A (18mm pin spacing), DIN EN 175301-803

  • Number of connectors: 2 independent valve plugs

  • Housing material: Black plastic with bright green LED indicator frames

  • Contact area: 27 x 27 mm square spade connectors

  • Cable exit: 90-degree angled exit for space-saving installation

  • Locking: Internal screw lock prevents accidental disconnection

• Wiring Configuration

  • Parallel wiring: Both MSUD valve connectors share common M12 power

  • Pin 1 (M12): Positive supply, distributed to both valves

  • Pin 2 (M12): Negative/return, common to both valves

  • Pin 3 (M12): Protective earth, bridged to both valve connectors

  • Independent LED circuits for each valve enable separate status indication

• Compatibility

  • M12 side: Works with fieldbus drops, I/O modules, PLC outputs, valve terminals

  • Valve side: Compatible with MSUD Form A 18mm coils from ASCO, Festo, Parker, Norgren

  • Ideal for converting single M12 connection to dual valve control

  • Perfect for decentralized valve manifolds with M12 connection topology

• Features & Applications

  • Single M12 connection powers two independent valve coils

  • Independent green LEDs simplify troubleshooting and status monitoring

  • Compact design reduces wiring complexity in valve islands

  • IP67 M12 connection suitable for harsh and wet environments

  • Operating temperature: -10°C to +80°C

  • Storage temperature: -25°C to +70°C

  • Ideal for pneumatic valve banks, hydraulic manifolds, automated assembly

  • Common in food processing, packaging, pharmaceutical, automotive industries

• Additional Information

  • CE marked for European compliance

  • cULus certified for North American applications

  • RoHS compliant, lead-free materials

  • Pre-wired eliminates field assembly and wiring errors

  • Robust PUR cable resists oils, chemicals, abrasion, and coolants

  • Suitable for both fixed installation and limited flex applications

  • Screw-lock connections ensure vibration-resistant mounting

  • German engineering ensures reliability in demanding industrial environments
