Murr M12 to MSUD Double Valve Connector 24V AC/DC LED Form A 18mm Cable NEW

Murr M12 to MSUD Double Valve Connector 24V AC/DC LED Form A 18mm Cable NEW

- Shipping includes tracking info worldwide. Klaus KLJ Trading

• Brand & Model

  • Manufacturer: Murr Elektronik, Czech Republic

  • Type: M12 male to dual MSUD valve plug Y-cable adapter

  • Model Type: M12 A-coded to 2x MSUD Form A valve connectors

  • Cable marking visible: 7G0.75 (7 conductors x 0.75 mm²)

  • Condition: New, never used, fully functional

• Technical Specifications

  • Voltage rating: 24V AC/DC universal

  • AC voltage tolerance: Plus or minus 20 percent

  • DC voltage tolerance: Plus or minus 25 percent

  • Current rating: 4A maximum per valve connector

  • M12 connector: Male, 4 or 5-pin A-coded, straight orientation

  • Valve connector type: 2x MSUD Form A, 18mm pin spacing

  • Protection rating: IP67 on M12 side when mated, IP65 on valve side

• Cable Construction

  • Cable specification: 7G0.75 multi-conductor cable

  • Conductor cross-section: 0.75 mm² per wire

  • Number of conductors: 7 wires total

  • Cable jacket: PUR (polyurethane) or PVC, gray color

  • Cable length: Approximately 200-300mm total

  • Y-cable configuration: Single M12 input splits to two MSUD outputs

• M12 Connector Features

  • Connection type: M12 male, 4 or 5-pin A-coded

  • Pin orientation: Straight (0 degree)

  • Connector body: Metal threaded coupling nut with nickel plating

  • Locking mechanism: Screw-thread coupling for vibration resistance

  • Contact material: Gold-plated pins for reliable conductivity

  • Cable entry: Straight rear entry with strain relief

• MSUD Valve Connector Features

  • Valve standard: Form A (18mm pin spacing), DIN EN 175301-803

  • LED indicators: Green bidirectional LEDs on both valve connectors

  • LED function: Visual indication of voltage presence on each coil

  • Housing material: Black plastic with bright green LED frames

  • Contact area: 27 x 27 mm square spade connector

  • Suppression: Integrated Z-diode or varistor for spike protection

• Wiring Configuration

  • Parallel wiring: Both valve connectors share common M12 power supply

  • Pin 1: Positive supply (brown wire typical)

  • Pin 2: Negative/return (blue wire typical)

  • Pin 3: Protective earth (green/yellow, bridged between both valves)

  • Independent LED circuits for each valve connector

• Compatibility

  • M12 side: Compatible with M12 A-coded fieldbus drops, I/O modules, valve terminals

  • Valve side: Works with MSUD Form A 18mm coils (ASCO, Festo, Parker, Norgren compatible)

  • Ideal for converting single M12 output to dual valve control

  • Perfect for valve manifolds requiring decentralized M12 connection

• Features & Applications

  • Y-splitter design allows single M12 connection to power two valves

  • Independent green LED indicators simplify troubleshooting

  • Compact design reduces wiring complexity in valve islands

  • IP67 M12 connection suitable for wash-down environments

  • Operating temperature: -10°C to +80°C

  • Ideal for pneumatic valve banks, hydraulic manifolds, automated machinery

  • Common in food processing, packaging, automotive, pharmaceutical industries

• Additional Information

  • CE marked for European compliance

  • cULus certified for North American markets

  • RoHS compliant construction

  • Pre-wired eliminates field assembly errors

  • Robust PUR cable resists oils, chemicals, and abrasion

  • Can be used in cable track applications with proper bending radius

  • Screw-lock M12 connector prevents accidental disconnection
